| Parameter |
Value |
| Contact &
Voltage Ratings |
250mA, 250V AC |
| Contact
Arrangement |
2 NO, 2NC |
| Contact
Resistance(Max Initial) |
25 m Ohms |
| Electrical
Life |
3,00,000 Cycles |
| H. V. Breakdown
Test |
1.5 KVAC For 1 minute |
| Insulation
Resistance at 500V DC (Min) |
1000 M Ohms |
| Material -
Body |
Polycarbonate |
| Material -
Terminals |
Brass, Silver plated |
| Mounting |
PCB-type |
| Permissible Temp
For Soldering |
270 deg. C for 5 sec. max. |
| Permissible Temp
For With/Without Load |
-20 deg. C to +85 deg. C. |
| Product
Weight |
3.0 gm Max. . |
| Switch
Type |
Momentary On |
| Terminal
Style |
Solder-type |
| Test
Specification |
IEC-1020 - (1991) |
|
