Terminals (Binding Post)

Terminals - BTI-15


    Description

    CACT / C-DOT / LCSO Approved

    Technical Specifications


Parameter Value
Approvals LCSO, CACT, C-DOT .
Contact Resistance 5 m ohms max. (Initial)
Current Carrying Parts Terminals: Brass, Nickel Plated.
Current Rating 15 Amps, 250V AC
H. V. Breakdown Test 2 KVAC for 1 Minute .
Insulation Resistance(Min) 1000 M Ohms min.
Material Polyamide
Mounting Front
Panel Thickness 3.0 max.
Product App. Weight(Max) 12.0 gms
Terminals Screw-type
Test Specification JSS 52710(1994) TYPE TSC - 10 - N .
Type Panel Mounting


Terminals - BTI-30


    Description

    CACT / LCSO Approved

    Technical Specifications


Parameter Value
Approvals LCSO, CACT .
Contact Resistance 20 m Ohms
Current Carrying Parts Terminals: Brass, Nickel Plated .
Current Rating 30 Amps @ 250V AC
H. V. Breakdown Test 2 KV/AC For 1 Minute .
Insulation Resistance(Min) 1000 M Ohms
Material Polyamide
Product App. Weight(Max) 22 gm .
Test Specification JSS 52710(JAN1994) TYPE TSC - 11 - N .
Type Panel Mounting


Terminals - BTI-5


    Technical Specifications


Parameter Value
Contact Resistance 5 m Ohms Max.
Current Rating 5 Amps @ 250V AC
H. V. Breakdown Test 2 KV AC
Insulation Resistance(Min) 1000 M Ohms Min.
Mounting Front
Panel Thickness 2.5 Max.
Permissable Temp.With / Without Load -20 deg. C to + 85 deg. C
Reference Standards JSS 52710
Terminals Screw Type
Type Panel Mounting
