| Parameter |
Value |
| Card Thickness |
1.42 mm - 1.8 mm |
| Contact Resistance, Max(Initial) |
10 m Ohms |
| Contact Termination |
Solder / PCB Mountable |
| H. V. Break Down |
1.5 KV |
| Insulation Resistance(Min) |
1000 M Ohms |
| Material Body |
Polycarbonate |
| Material Contacts |
Phosphor Bronze, Gold, Silver or Tin Plated . |
| Mechanical Life |
500 Cycles . |
| No. of Contacts |
24,44 |
| Rated Current |
5 Amp. At 300 Volts rms |
| Temperature(Max) |
80 Deg. C |
| Type |
Printed Circuit Connector With Bellows Contact |
|
| |
| |
|
|
|
| |
|
| |
| |
