Mighty Mini Fan - UF383-100
(8X8X3 mm) |
|
|
|
FEATURES : |
 |
Operating Voltage |
: |
2.1~3.5 V |
|
|
Voltage |
: |
3V |
|
|
Power Current |
: |
93 mA |
|
|
Power Consumption |
: |
0.30 Watts |
|
|
Speed |
: |
13500 RPM |
|
|
Air Flow |
: |
0.17l/min |
|
|
Static Pressure |
: |
1.56 Pa |
|
|
Noise |
: |
- - - |
|
|
Lead Wire |
: |
FPCB (3rd Ftype) |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
 |
Mighty Mini Fan - UF385-100
(8x8x5 mm) |
|
|
|
FEATURES : |
|
|
Operating Voltage |
: |
2.0~3.5 V |
|
|
Voltage |
: |
3V |
|
|
Power Current |
: |
49 mA |
|
|
Power Consumption |
: |
0.10 Watts |
|
|
Speed |
: |
17000 RPM |
|
|
Air Flow |
: |
0.611/min |
|
|
Static Pressure |
: |
2.98 Pa |
|
|
Noise |
: |
- - - |
|
|
Lead Wire |
: |
FPCB (3rd F type) |
|
|
|
|
|
|
|
|
| |
 |
Mighty Mini Fan
UF3A3-500 - UF3A3-700
(10x10x3 mm) |
|
|
|
FEATURES : |
|
|
Operating Voltage |
: |
2.0~3.5 V |
|
|
Voltage |
: |
3V |
|
|
Power Current |
: |
96 mA |
|
|
Power Consumption |
: |
0.29 Watts |
|
|
Speed |
: |
17000 RPM |
|
|
Air Flow |
: |
3.431/min |
|
|
Static Pressure |
: |
10.44 Pa |
|
|
Noise |
: |
- - - |
|
|
Lead Wire |
: |
3 Wires (3rd Ftype) / 2 Wires |
|
|
|
|
|
|
|
|
| |
|
|
Mighty Mini Fan
UF3C3-500 - UF3C3-700
(12x12x3 mm) |
|
|
|
FEATURES : |
|
|
Operating Voltage |
: |
2.0~3.5 V |
|
|
Voltage |
: |
3V |
|
|
Power Current |
: |
97 mA |
|
|
Power Consumption |
: |
0.30 Watts |
|
|
Speed |
: |
16500 RPM |
|
|
Air Flow |
: |
5.951/min |
|
|
Static Pressure |
: |
18.91 Pa |
|
|
Noise |
: |
- - - |
|
|
Lead Wire |
: |
3 Wires (3rd Ftype) / 2 Wires |
|
|
|
|
|
|
|
|
| |
 |
Mighty Mini Fan
UF3F3-500 - UF3F3-700
(15X15X3 mm) |
|
|
|
FEATURES : |
|
|
Operating Voltage |
: |
2.0~3.5 V |
|
|
Voltage |
: |
3V |
|
|
Power Current |
: |
36 mA |
|
|
Power Consumption |
: |
0.10 Watts |
|
|
Speed |
: |
14500 RPM |
|
|
Air Flow |
: |
8.751/min |
|
|
Static Pressure |
: |
20.36 Pa |
|
|
Noise |
: |
30.9 dBA/30cm |
|
|
Lead Wire |
: |
3 Wires (3rd Ftype) / 2 Wires |
|
|
|
|
|
|
|
|
| |
|
|
Mighty Mini Fan
UF3H3-500 - UF3H3-700
(17X17X3 mm) |
|
|
|
FEATURES : |
|
|
Operating Voltage |
: |
2.0~3.5 V |
|
|
Voltage |
: |
3V |
|
|
Power Current |
: |
37 mA |
|
|
Power Consumption |
: |
0.10 Watts |
|
|
Speed |
: |
13000 RPM |
|
|
Air Flow |
: |
16.27/min |
|
|
Static Pressure |
: |
18.55 Pa |
|
|
Noise |
: |
32.0 dBA/30cm |
|
|
Lead Wire |
: |
3 Wires (3rd Ftype) / 2 Wires |
|
|
| |
|
